Thermal Evaporation Metalizing System
Vacuum Aluminium Coating Machine
A physical vapour deposition system that deposits mirror-bright aluminium layers onto plastics, glass and other substrates — stainless-steel chamber, 440 V automatic operation.
Product Overview
Vacuum Aluminium Coating Machine
AA vacuum metalizing machine (also called a vacuum metallization system) is a coating device that deposits a thin, uniform metallic layer onto a substrate through physical vapor deposition (PVD), most commonly thermal evaporation. The process occurs inside a sealed vacuum chamber where metal, usually aluminum, is heated until it vaporizes and condenses onto the target surface.
Inside the 2200 × 3600 mm stainless-steel chamber, aluminium wire is thermally evaporated under vacuum and condenses as a uniform metallic film on the racked substrates. The 440 V three-phase system runs automatically with front-door loading, producing the mirror finishes used on cosmetic caps, auto reflectors, decorative trims and metalized films.
Mirror-Bright Aluminium
Thermal evaporation lays down an even aluminium film that turns plastic parts into chrome-look components.
-
Uniform thin-film deposition -
Mirror and matte finishes -
Excellent adhesion -
Lacquer top-coat compatible
One Chamber, Many Parts
Rack systems adapt the chamber to caps, reflectors, trims and roll goods — one machine serving multiple industries.
-
Cosmetic caps & closures -
Auto lamp reflectors -
Decorative trims & toys -
Metalized films and sheets
In Detail
Image Gallery
See It In Action
Product Videos
Vacuum Coating Machine
The vacuum metalizing chamber and process.
Technical Data Set
Technical Specifications
Applications
Automotive Reflectors
Head-lamp and indicator reflector metalizing.
Cosmetics Packaging
Chrome-look caps, closures and compacts.
Decorative Products
Trims, toys and giftware finishes.
Coating Job Shops
Contract metalizing service providers.
Support
Frequently Asked Questions
How does the machine work?
What parts can be coated?
What utilities does it need?
Is a top coat needed?
Request a Quote
Connect with our engineering team for detailed technical specifications, tailored configurations, and volume pricing on our Vacuum Aluminium Coating Machine range — with expert support from selection through delivery and after-sales service.
-
Rigorous in-house quality control -
Global logistics and customs support -
Material traceability and COA provided
