Biaxially Oriented PP Film Line

BOPP Film Production Line

A complete biaxially oriented polypropylene film plant — extrusion, cast sheet, MDO/TDO stretching, haul-off, winding and slitting — producing 15–50 µm film at 10,000 tons per year.

View Specifications Request Quote
BOPP Film Production Line
10,000 t/yr

Product Overview

BOPP Film Production Line

Biaxially Oriented Polypropylene Film Product Line consists raw material system, extrudsion system, cast sheet system, Longitudinal stretching unit, Transverse stretching unit, a haul-off unit, winding unit, slitting unit, automatic control system. Additional Information: Production Capacity: 10,000 T/year. Delivery Time: 90 days.

The 115 × 9 × 4 m line integrates raw material handling, extrusion, cast sheet forming, longitudinal and transverse stretching, haul-off, winding and slitting under one automatic control system, drawing about 1600 kW. It delivers 15–50 µm film at 10,000 tons per year — the packaging film behind lamination, printing, tapes and labels.

Complete

Resin to Slit Rolls

Every stage of BOPP production integrated and synchronized under one automatic control system.

  • Raw material & extrusion systems
  • Cast sheet unit
  • MDO + TDO stretching
  • Winding & slitting units
Resin to Slit Rolls
Film

15–50 µm Precision Film

Biaxial stretching gives BOPP its clarity, stiffness and strength — the standard film for flexible packaging.

  • Biaxial orientation
  • 15–50 µm thickness range
  • Uniform gauge profile
  • High clarity and strength
15–50 µm Precision Film
Scale

10,000 Tons a Year

A plant-scale investment that anchors a flexible packaging business with national supply capacity.

  • Industrial line economics
  • 115 m integrated plant
  • ≈1600 kW installed
  • 1-year warranty
10,000 Tons a Year

In Detail

Image Gallery

BOPP film production line
BOPP film production line catalogue
BOPP film production line

See It In Action

Product Videos

BOPP Film Production Line

The complete BOPP line from extrusion to winding.

BOPP Film Production Line — Walkthrough

Stretching, haul-off and winding sections.

Technical Data Set

Technical Specifications

Phase
3 phase
Weight
≈ 350 t
Product
BOPP film, 15 – 50 µm
Capacity
10,000 tons/year
Warranty
1 year
Dimension
115 × 9 × 4 m
Total Power
≈ 1600 kW
Availability
Made to order
Machine Type
Automatic
Raw Material
Polypropylene (PP)
Line Composition
Extrusion, cast sheet, MDO, TDO, haul-off, winding, slitting

Applications

Flexible Packaging

Lamination and printing films for food packaging.

Tapes & Labels

Base film for adhesive tapes and labels.

Lamination Film

Document and print lamination films.

Film Producers

Turnkey BOPP capacity for converters.

Support

Frequently Asked Questions

What does the line consist of?
Raw material system, extrusion, cast sheet unit, longitudinal (MDO) and transverse (TDO) stretching, haul-off, winding and slitting — all under one automatic control system.
What film can it produce?
Biaxially oriented polypropylene film from 15 to 50 µm at up to 10,000 tons per year.
What is BOPP film used for?
Food packaging lamination, printing films, adhesive tapes and labels — it is the workhorse film of flexible packaging.
What are the installation requirements?
The line measures about 115 × 9 × 4 m, weighs around 350 tons and draws approximately 1600 kW of three-phase power.
